• Technology: Mifare/Blutooth
• LED: Three -state standard (red, green, off)
• Audible Tone: Beeper
• Operating Frequency: 13.56 Mhz.
• Power Requirement: 12 VDC
• Current Draw: 35 mA typical, 90 mA peak at card read
• Operating Temp. Range: -40° F to 140° F/-40° C to +60° C
• IP Code: IP66
• Size (Mullion): 4.1(H) x 1.89(W) x .748(D) inches 104(H) x 48(W) x 19(D) mm
• Adaptor Plate for Single Gang Mount
• Weight 260 grams
• Cable Req.: 6 Conductor, 22 AWG, Stranded, Overall Shield

Application

Slim mount design makes this reader ideal for applications such as door access, entry and parking barriers.

User Friendly

Users need only to present their smartphone to be granted access. Alternatively, you may present a Mifare Card credential should your phone not be avaialble.

Industry Standard

Compatible with Mifare Tags or Blutooth enabled Smartphones > IOS7.0 or Android 4.3 and above.

Performance

Delivers non-contact read ranges for Mifare cards from 2~6 cm. Blutooth enabled phones have a range of ~100 cm.

Resilient

Secured with tamper weather-resistant epoxy
